Collecting Telemetry from On-Premises and Cloud-Based Applications

collect telemetry from app

Overview

This guide demonstrates how to collect telemetry—logs, metrics, and traces—from applications running in both on-premises environments and cloud-based infrastructure using OpenTelemetry. It covers setup instructions for the OpenTelemetry Collector outside Kubernetes using Docker Compose and shows how to instrument applications for observability.

For Kubernetes-native workloads, refer to the articles below:

This guide extends those approaches to applications deployed outside Kubernetes environments.

OpenTelemetry Components

The primary OpenTelemetry components used in this guide are:

  • OpenTelemetry Collector: A service for receiving, processing, and exporting telemetry data.

  • OpenTelemetry SDKs and Agents: Language-specific libraries and instrumentation agents for generating telemetry from applications.

Deploying the OpenTelemetry Collector via Docker Compose

To simplify the setup, Docker Compose is used to deploy the OpenTelemetry Collector and its dependencies locally without requiring a Kubernetes cluster.

If you’re deploying a full observability stack on Kubernetes, refer to:

Docker Compose Setup

Create a docker-compose.yaml file with the following content:

docker-compose.yaml
version: '3'

services:
  otel-collector:
    image: otel/opentelemetry-collector-contrib
    #(1)
    volumes:
      - ./otel-collector-config.yaml:/etc/otelcol-contrib/config.yaml
    ports:
      - 1888:1888 # pprof extension
      - 8888:8888 # Prometheus metrics exposed by the Collector
      - 8889:8889 # Prometheus exporter metrics
      - 13133:13133 # health_check extension
      - 4317:4317 # OTLP gRPC receiver
      - 4318:4318 # OTLP http receiver
      - 55679:55679 # zpages extension
1 This mounts the OpenTelemetry Collector configuration file into the container.

OpenTelemetry Collector Configuration

This configuration uses a debug exporter to print collected telemetry to the console.

otel-collector-config.yaml
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318
processors:
  batch:
    send_batch_size: 10000
    timeout: 10s

exporters:
  debug:
    verbosity: detailed

service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [batch]
      exporters: [debug]
    metrics:
      receivers: [otlp]
      processors: [batch]
      exporters: [debug]
    logs:
      receivers: [otlp]
      processors: [batch]
      exporters: [debug]

Start OpenTelemetry Collector

To start the Collector:

$ docker-compose up

Telemetry data will be printed in the terminal when received.

Instrumenting Applications with OpenTelemetry SDKs

Java Application

You can use the following example repository:

https://github.com/nsalexamy/otel-spring-example

Java Agent

Download the latest version of the OpenTelemetry Java agent from:

You can find the opentelemetry-javaagent.jar file in the otel-spring-example repository under the javaagent directory.

To enable the agent, you can use -javaagent option or JAVA_TOOL_OPTIONS environment variable like below.

$ export JAVA_TOOL_OPTIONS="-javaagent:javaagent/opentelemetry-javaagent.jar"

Configuring Environment Variables

To instrument the Java application with OpenTelemetry, you need to set the following environment variables:

  • OTEL_SERVICE_NAME: The name of the service that will be reported in the telemetry data.

  • OTEL_EXPORTER_OTLP_ENDPOINT: The endpoint of the OpenTelemetry Collector to which the telemetry data will be sent.

  • OTEL_TRACES_EXPORTER: The exporter to use for traces. Default is otlp.

  • OTEL_LOGS_EXPORTER: The exporter to use for logs. Default is otlp.

  • OTEL_METRICS_EXPORTER: The exporter to use for metrics. Default is otlp.

  • OTEL_METRIC_EXPORT_INTERVAL: The interval at which metrics will be exported. Default is 60000 milliseconds.

  • OTEL_EXPORTER_PROMETHEUS_PORT: The port on which the Prometheus exporter will expose metrics. Default is 9464.

Set the following environment variables to configure the agent:

$ export OTEL_SERVICE_NAME=otel-spring-example
$ export OTEL_EXPORTER_OTLP_ENDPOINT=http://localhost:4318

Running the Application

To run the Java application with OpenTelemetry instrumentation, use the following command:

$ ./gradlew clean bootRun
$ java -javaagent:javaagent/opentelemetry-javaagent.jar -jar build/libs/otel-spring-example-0.0.1-SNAPSHOT.jar --server.port=8080

Generating Telemetry Data

  • Metrics are automatically exported at intervals using the Java agent.

  • Logs are emitted via application logging.

  • Traces are generated by sending HTTP requests to the application.

Example:

$ curl http://localhost:8080/error/cause/0.3

This triggers a trace and logs an error (30% chance of HTTP 500).

Metrics Exporter Considerations

Use one of the following exporters:

  • otlp: Best suited for external or local development environments.

  • prometheus: Exposes metrics at /metrics, ideal for use in Kubernetes.

To use the Prometheus exporter:

$ export OTEL_METRICS_EXPORTER=prometheus
$ export OTEL_EXPORTER_PROMETHEUS_PORT=9464

If you restart the application, you can see the metrics being collected by the OpenTelemetry Collector in the console where it is running.

http://localhost:9464/metrics

The port 9464 is the default port for the OpenTelemetry Collector to expose the Prometheus metrics.

OpenTelemetry Environment Variable Specification

Refer to the link below for the complete list of OpenTelemetry environment variables that can be used to configure the OpenTelemetry Java agent:

https://opentelemetry.io/docs/specs/otel/configuration/sdk-environment-variables/

Collecting Container Metrics

For container-level metrics, use the OpenTelemetry Collector with the cadvisor receiver. Details:

Real-World Deployment

In production: * Deploy the OpenTelemetry Collector in Kubernetes. * For external applications, expose the Collector using an Ingress or LoadBalancer. * Set OTEL_EXPORTER_OTLP_ENDPOINT accordingly for external clients.

Visualizing Telemetry Data in Grafana

Use Grafana to visualize metrics, traces, and logs collected via the OpenTelemetry Collector. This can be integrated with Prometheus, Jaeger, and OpenSearch as telemetry backends.

Conclusion

This guide provided a practical approach for collecting telemetry from applications deployed outside Kubernetes environments using OpenTelemetry. You learned how to deploy the Collector with Docker Compose, configure a Java application with the OpenTelemetry Java agent, and generate and inspect telemetry data.
