Kaniko Tutorial - Build and Push a Python App to Amazon ECR

Introduction

This tutorial is the second installment in the Kaniko series. It demonstrates how to build a Python application and push the resulting Docker image to Amazon ECR (Elastic Container Registry) using Kubernetes.

In this guide, you will learn how to:

Create a Dockerfile for a simple Python application
Host application code in a GitHub repository
Define Kubernetes ConfigMaps and Secrets for the build context and AWS credentials
Set up IAM roles and policies for image pushing using Terraform
Run a Kaniko pod to build and push the image

Prerequisites

Make sure the following tools and configurations are in place:

A running Kubernetes cluster
kubectl installed and configured
Docker Hub or Amazon ECR account
AWS CLI installed and configured with access to ECR
Terraform installed

Step 1: Prepare the Python Application

GitHub Repository

We’ll use a simple Python app hosted on GitHub:

https://github.com/nsalexamy/kaniko-python-app

Files used:

app.py: A Python script printing a greeting
requirements.txt: Dependency file (empty or with basic packages like Flask)

app.py

# main function
def main():
    print("starting the application...")
    print("Hello from inside the container!")


if __name__ == "__main__":
    main()

requirements.txt

# docker-context/requirements.txt
# Leave it empty or add:
# flask==2.3.2

Step 2: Kubernetes Setup

Create a Namespace

Run the following to create the namespace:

$ kubectl get namesapce kaniko &> /dev/null || kubectl create namespace kaniko

Define Dockerfile

Create a Dockerfile that installs dependencies and runs the app:

docker-context/Dockerfile

# docker-context/Dockerfile

# Use official Python image
FROM python:3.11-slim

# Set working directory
WORKDIR /app

# Copy requirements and install them
COPY requirements.txt .
RUN pip install --no-cache-dir -r requirements.txt

# Copy application code
COPY app.py .

# Default command
CMD ["python", "app.py"]

Create a ConfigMap for the Dockerfile

$ kubectl -n kaniko create configmap kaniko-python-app-dockerfile \
  --from-file=docker-context/Dockerfile \
  --dry-run=client -o yaml \
  | yq eval 'del(.metadata.creationTimestamp)' \
  > kaniko-python-app-dockerfile-configmap.yaml


# Apply the manifest

$ kubectl apply -f kaniko-python-app-dockerfile-configmap.yaml

Create a Secret for AWS Credentials

Set environment variables:

$ export AWS_ACCESS_KEY_ID=your-aws-access-key-id
$ export AWS_ACCOUNT_ID=your-aws-account-id
$ export AWS_SECRET_ACCESS_KEY=your-aws-secret-access-key
$ export AWS_REGION=your-aws-region

Create the Kubernetes secret:

$ kubectl -n kaniko create secret generic aws-secret \
  --from-literal=AWS_ACCESS_KEY_ID=$AWS_ACCESS_KEY_ID \
  --from-literal=AWS_ACCOUNT_ID=$AWS_ACCOUNT_ID \
  --from-literal=AWS_SECRET_ACCESS_KEY=$AWS_SECRET_ACCESS_KEY \
  --from-literal=AWS_REGION=$AWS_REGION

Step 3: IAM Role Setup with Terraform

Amazon provides the managed policy EC2InstanceProfileForImageBuilderECRContainerBuilds which grants Kaniko the necessary permissions to push images to ECR.

Refer to the official Kaniko ECR guide: https://github.com/GoogleContainerTools/kaniko?tab=readme-ov-file#pushing-to-amazon-ecr

Terraform Configuration

The following Terraform code creates an IAM role for Kaniko with the necessary permissions to push images to ECR.

The variables are defined in the variables.tf file, and the values are set in the terraform.tfvars file.

terraform/variables.tf

variable "aws_region" {
  description = "AWS region where EKS is deployed"
  type        = string
}

variable "eks_cluster_name" {
  description = "EKS cluster name"
  type        = string
}

variable "namespace" {
  description = "Kubernetes namespace where Kaniko runs"
  type        = string
  default     = "kaniko"
}

terraform/terraform.tfvars

aws_region       = "your-aws-region"
eks_cluster_name = "your-eks-cluster-name"
namespace        = "kaniko"

kaniko-irsa.tf

provider "aws" {
  region = var.aws_region
}

provider "kubernetes" {
  config_path = "~/.kube/config"
}

# Get AWS and EKS context
data "aws_caller_identity" "current" {}

data "aws_eks_cluster" "cluster" {
  name = var.eks_cluster_name
}

data "aws_eks_cluster_auth" "cluster" {
  name = data.aws_eks_cluster.cluster.name
}

# Use existing Policy - EC2InstanceProfileForImageBuilderECRContainerBuilds
data "aws_iam_policy" "ecr_container_builds" {
  name = "EC2InstanceProfileForImageBuilderECRContainerBuilds"
}

# Create IAM Role for IRSA
resource "aws_iam_role" "kaniko_irsa_role" {
  name = "kaniko-irsa-role"

  assume_role_policy = jsonencode({
    Version = "2012-10-17",
    Statement = [
      {
        Effect = "Allow",
        Principal = {
          Federated = "arn:aws:iam::${data.aws_caller_identity.current.account_id}:oidc-provider/${replace(data.aws_eks_cluster.cluster.identity[0].oidc[0].issuer, "https://", "")}"
        },
        Action = "sts:AssumeRoleWithWebIdentity",
        Condition = {
          StringEquals = {
            "${replace(data.aws_eks_cluster.cluster.identity[0].oidc[0].issuer, "https://", "")}:sub" = "system:serviceaccount:${var.namespace}:kaniko-builder-sa"
          }
        }
      }
    ]
  })
}

# Attach the policy to the role
resource "aws_iam_role_policy_attachment" "kaniko_policy_attach" {
  role       = aws_iam_role.kaniko_irsa_role.name
  policy_arn = data.aws_iam_policy.ecr_container_builds.arn
}

# Create Kubernetes service account annotated with IRSA role
resource "kubernetes_service_account" "kaniko_sa" {
  metadata {
    name      = "kaniko-builder-sa"
    namespace = var.namespace
    annotations = {
      "eks.amazonaws.com/role-arn" = aws_iam_role.kaniko_irsa_role.arn
    }
  }
}

Apply Terraform

$ cd terraform

$ terraform init
$ terraform plan
$ terraform apply -var-file="terraform.tfvars"

Example output:


aws_iam_role.kaniko_irsa_role: Creating...
aws_iam_role.kaniko_irsa_role: Creation complete after 1s [id=kaniko-irsa-role]
aws_iam_role_policy_attachment.kaniko_policy_attach: Creating...
kubernetes_service_account.kaniko_sa: Creating...
aws_iam_role_policy_attachment.kaniko_policy_attach: Creation complete after 0s [id=kaniko-irsa-role-20250501032807987700000001]
kubernetes_service_account.kaniko_sa: Creation complete after 0s [id=kaniko/kaniko-builder-sa]

Following resource will be created:

kaniko-irsa-role : IAM role for Kaniko
kaniko_policy_attach : IAM policy attachment
kaniko-builder-sa : Kubernetes service account for Kaniko

Kubernetes Service Account (kakinoko-builder-sa)

Now the service account 'kaniko-builder-sa' is created in the 'kaniko' namespace. This service account is associated with the IAM role created above.

show the service account

$ kubectl -n kaniko get sa kaniko-builder-sa -o yaml

Example output:

apiVersion: v1
automountServiceAccountToken: true
kind: ServiceAccount
metadata:
  annotations:
    eks.amazonaws.com/role-arn: arn:aws:iam::{your-aws-account-id}:role/kaniko-irsa-role
  creationTimestamp: "2025-05-01T03:28:08Z"
  name: kaniko-builder-sa
  namespace: kaniko
  resourceVersion: "136704"
  uid: c4db2da1-36bd-4d3b-85a7-4067507c1031

Note: The IAM role is associated with the service account using the annotation 'eks.amazonaws.com/role-arn'.

It is important to note that the service account must be used in the Kaniko pod manifest. The pod will use this service account to assume the IAM role and gain permissions to push images to ECR.

Step 4: Kaniko Pod to Build and Push Image

In this step, we will create a Kaniko pod that will build the Docker image and push it to ECR.

In the manifest file, we will specify the following:

GitHub repository for Docker context
Dockerfile
Docker config.json
Service account with permissions to push to ECR

kaniko-python-app-pod.yaml

apiVersion: v1
kind: Pod
metadata:
  generateName: kaniko-python-app-
  namespace: kaniko
spec:
  # service account with permissions to push to ECR
  #(1)
  serviceAccountName: kaniko-builder-sa

  initContainers:
    #(2)
    - name: create-ecr-repo
      image: amazonlinux
      command: ["/bin/sh", "-c"]
      args:
        - |
          yum install -y aws-cli && \
          echo "Checking or creating ECR repository..." && \
          aws ecr describe-repositories --region ca-west-1 --repository-names kaniko-python-app || \
          aws ecr create-repository --region ca-west-1 --repository-name kaniko-python-app
      envFrom:
        - secretRef:
            name: aws-secret

    #(3)
    - name: setup-ecr-auth
      image: amazonlinux
      command: [ "/bin/sh", "-c" ]
      args:
        - |
          yum install -y aws-cli docker && \
          mkdir -p /kaniko/.docker && \
          aws ecr get-login-password --region ca-west-1 \
            | docker login --username AWS \
                          --password-stdin 123456789012.dkr.ecr.ca-west-1.amazonaws.com && \
          cp ~/.docker/config.json /kaniko/.docker/config.json
      volumeMounts:
        - name: docker-config
          mountPath: /kaniko/.docker
      envFrom:
        - secretRef:
            name: aws-secret

  containers:
    - name: kaniko
      #(4)
      image: gcr.io/kaniko-project/executor:latest
      #(5)
      args: ["--dockerfile=/workspace/Dockerfile",
             "--context=git://github.com/nsalexamy/kaniko-python-app.git#refs/heads/main",
             "--destination=123456789012.dkr.ecr.ca-west-1.amazonaws.com/kaniko-python-app"] # replace with your dockerhub account

      volumeMounts:
        - name: dockerfile-storage
          mountPath: /workspace
        - name: docker-config
          mountPath: /kaniko/.docker


  restartPolicy: Never
  volumes:
    - name: dockerfile-storage
      configMap:
        name: kaniko-python-app-dockerfile
    - name: docker-config
      emptyDir: {}

1	Service account with permissions to push to ECR
2	Init container to create ECR repository if it doesn’t exist
3	Init container to set up ECR authentication
4	Kaniko executor image
5	Kaniko arguments to build and push the image

To run the Kaniko pod, use the following command:

$ kubectl create -f kaniko-python-app-pod.yaml

# Example output:

pod/kaniko-python-app-z77fr created

Step 5: Verify the Image in ECR

Once the Kaniko pod completes, you should see the image in your Amazon ECR repository.

Figure 1. kaniko-python-app image in ECR

Step 6: Run the Image

Run the built image directly in Kubernetes:

$ kubectl -n kaniko run -it --rm kaniko-python-app \
  --image=${AWS_ACCOUNT_ID}.dkr.ecr.ca-west-1.amazonaws.com/kaniko-python-app \
  --restart=Never

*Expected output*:

starting the application...
Hello from inside the container!
pod "kaniko-python-app" deleted

Step 7: Clean Up Resources

To delete the IAM role and associated resources:

$ cd terraform
$ terraform plan -destroy
$ terraform destroy

Conclusion

In this tutorial, you learned how to:

Build a Docker image for a Python app using Kaniko
Push the image to Amazon ECR
Set up Kubernetes and AWS resources using Terraform
Securely manage credentials and permissions using IAM and service accounts

This process allows you to containerize applications and automate delivery pipelines in a secure and Kubernetes-native way.
